| Based On | Boss NF-1 Noise Gate |
|---|
Schematics, circuits, PCBs and veroboards for guitar effects pedals.
The Boss NF-1 is a versatile pedal that offers overdrive, compression, and boosting capabilities. It is particularly effective for use with single-coil pickups, but it may not perform optimally with lower quality cables, resulting in increased hum and noise at higher gain levels. To address this issue, the pedal features a built-in noise gate. The circuit of the NF-1 is based on the original design, with the only modification being the addition of true bypass functionality. The pedal’s controls allow for precise adjustment of the overdrive, compression, and boost settings to achieve the desired tone.
Download Schematic
